Inter-Tech 88881185 Ficha de datos descargar pdf (Pagina 2)

Errors excepted. No warranty for the correctness of the information State: 09.07.2013

Specifications

Motherboard

ITX

Drive Bays

3.5" internal: 1/0¹

2.5" internal: 1/2¹

Front Connectors

USB 3.0: 1

USB 2.0: 1

Microphone: 1

Headphone: 1

External Connectors

SATA data port: 1

4Pin Molex power connector: 1

Cooling System

3x 40x40x10mm

1x 60x60x10mm

(Rear, as option)

Packing Units

Shipping Unit: 1 Piece

Packing Unit: 4 Pieces

Guarantee and Warranty

Case 24 Months Warranty

Article Number

EAN-Code

88881185

4260133125582

Scope of Delivery

Cable ties

Screw set

2x dust filter

Features

ATX PSU mounting possible

2 full-size PCI cards possible

Side panels and bottom part detachable

4.5mm thick aluminum case

Rubber feet

USB 3.0, USB 2.0 and HD-Audio as block connector

¹in use of 2x 2.5" HDD, you will lose the possibility to mount 1x 3.5"HDD

Dimensions and Weight

Cage

Case

Package

Height

252mm

263mm

275mm

Width

222mm

300mm

Depth

212mm

220mm

295mm

Weight (net): 2.05Kg

Weight (gross): 2.65Kg

Certification:

Power Supply

Connector

Quantity

Max. Length

Mainboard 20+4Pin

P4 12V 4Pin

P4/EPS 4+4Pin

P8 12V 8Pin

PCI-Express 6+2Pin

PCI-Express 6Pin

IDE 4Pin

S-ATA

Floppy

RPM sensor cable

Fan Control

Fan: 120mm

1 2

Certification: 2
